Description
The EU-RN02L is a complete wall-mounted Dante or AES67 audio line output network interface. It features two balanced XLR line outputs on the front panel. The module is configured and adjusted using RDL CONSOLE or other network control software. The EU-RN02L fits a standard 60 mm deep European electrical box. The EU-RN02L is PoE powered and is supplied with a white front panel and cover plate. A field-installable black front panel laminate is included with the EU-RN02L.
Two Dante or AES67 audio channels are converted to balanced line level feeding front-panel XLR jacks. Each output provides balanced +4 dBu for a network digital audio level of -18 dBFS. Each output is equipped with a software-controlled attenuator adjustable in 1 dB steps to a maximum attenuation of 63 dB, then OFF.
Valid PoE power and synchronization to the Dante network are indicated by a green LED visible from the front of the unit.
The EU-RN02L is a professional grade product delivering studio-quality fidelity and low noise performance, coupled through XLR jacks housed in a steel chassis finished with a reverse-printed laminate.
The EU-RN02L’s superior performance specifications make it ideally suited to installations requiring network control and exceptional value in commercial networked audio systems. This full-featured product is engineered and manufactured in America with quality U.S. and imported components for continuous duty in demanding installations. Designed to outperform. Built to last.
Field-replaceable Black Laminate included. Black cover plate not included.
Two Dante or AES67 audio channels are converted to balanced line level feeding front-panel XLR jacks. Each output provides balanced +4 dBu for a network digital audio level of -18 dBFS. Each output is equipped with a software-controlled attenuator adjustable in 1 dB steps to a maximum attenuation of 63 dB, then OFF.
Valid PoE power and synchronization to the Dante network are indicated by a green LED visible from the front of the unit.
The EU-RN02L is a professional grade product delivering studio-quality fidelity and low noise performance, coupled through XLR jacks housed in a steel chassis finished with a reverse-printed laminate.
The EU-RN02L’s superior performance specifications make it ideally suited to installations requiring network control and exceptional value in commercial networked audio systems. This full-featured product is engineered and manufactured in America with quality U.S. and imported components for continuous duty in demanding installations. Designed to outperform. Built to last.
Field-replaceable Black Laminate included. Black cover plate not included.
