Description
The RU-RN40 modules are Dante/AES67 audio network interface products compatible with microphones and line-level audio equipment inputs and outputs. These modules are designed to be mounted in equipment racks, closets, conference tables and on shelves or backboards in commercial/industrial installations.
The RU-RN40 has four analog mic/line inputs and four Dante/AES67 network audio channel outputs. Each output stage is driven by an incorporated mixer fed from all four RU-RN40 inputs. Independent control of all mixer levels plus multiple DSP filters with adjustable parameters make the RU-RN40 far more versatile than a basic format converter. Each DSP filter may be set to None (audio pass-through), High-Pass, Low-Pass, Shelf High/Low or Notch Boost/Cut. Multiple filters may be set to the same function to obtain higher order filtering.
The RU-RN40 factory default settings provide high-quality conversion from four analog line-level, dynamic or condenser microphone sources to four Dante/AES67 network audio channels. The RU-RN40 provides an XLR or a detachable terminal block for connection to each analog input. Normal operating line level is +4 dBu balanced for -18 dBFS. The balanced terminal blocks may be wired unbalanced.
Consult the RU-RN40 functional block diagram in the image gallery to explore the wide range of configurations made possible by the mixing matrix design.
